Key Features & Benefits

• Intelligent Microprocessor Control: Displays set and actual operating parameters simultaneously on a high-visibility panel.

• Maintenance-Free Drive: Powered by a frequency conversion A.C. motor / DC brushless motor for smooth acceleration and quiet operation.

• Durable Construction: High-quality steel structure with a scratch-resistant powder-coated finish and a 304# stainless steel chamber that is autoclavable and resistant to detergents and disinfectants.

• Rotor Versatility: Compatible with aluminum alloy fixed angle rotors and stainless steel swing-out rotors, all designed with corrosion-free autoclavable construction.

• Advanced User Safety: Features active imbalance detection and automatic shutdown, safety lid interlock during rotor run, lid drop protection, and emergency door lock release in case of power failure.

• Smart Operation: Up to 29 program memory recall for repetitive analysis, real-time parameter modification during operation, automatic RPM/RCF conversion, and 10 acceleration/deceleration ramps.

  ⚙️ Technical Specifications

  Parameter	Specification (Model: BR-BC-5000)
  Model	BR-BC-5000
  Speed Range (rpm)	0 – 5000 rpm adjustable
  Speed Accuracy	±10 rpm
  Max Capacity (ml)	4 x 250 ml
  RCF Range (xg)	0 – 3686 xg adjustable
  Time Range	0 – 99 minutes 59 s
  Noise Level	<= 60 dB(A)
  Motor Type	Frequency Converter motor
  Acceleration / Deceleration Rates	0 – 9
  Display Panel	LCD (LED / TFT optional)
  Dimensions (mm)	570 x 440 x 250 mm
  Net Weight (without rotor)	38 KGS
  Power Supply	AC220V, 50HZ, 10A, 0.65KW
