Hybridization Oven BR-HDO-1000

The BR Biochem Hybridization Oven (BR-HDO-1000) features step motor technology and PID fuzzy control for high-precision temperature regulation and rapid heating, making it ideal for cloned gene screening, enzyme cutting map production, gene sequence detection, and clinical diagnostics.

Key Features & Benefits

  • Intuitive Interface: Vibrant, colorful LCD display allows for quick setup and real-time monitoring.

  • Quiet & Maintenance-Free: Powered by a step motor for noiseless, interference-free performance.

  • Precise Thermal Control: Uses PID fuzzy logic technology to ensure high temperature accuracy, auto-adjust heating rates, and allow built-in temperature calibration.

  • Durable Construction & Observation: Stainless steel interior for long service life, paired with a glass door for sample inspection without disturbing internal heat.

  • High Versatility & Storage: Accommodates various holders and platforms, with memory space for up to 99 customized programs.

  • Safety & Convenience: Equipped with built-in overheating protection, auto pre-heating, auto resume on power restoration, and an end-of-run completion alarm.

    ⚙️ Technical Parameters

    Parameter Specification
    Model BR-HDO-1000
    Temperature Control Range RT+5°C to 100°C (Setting range: 0°C to 100°C)
    Temperature Accuracy & Uniformity ≤±0.3°C (@37°C inside oven) / ≤±0.1°C (@37°C inside bottles)
    Rotation Speed Range 5 to 30 rpm
    Timer Range 1 min to 99h 59min / Continuous (∞)
    Maximum Load 5.0 kg
    Program Storage Up to 99 programs
    Interior / Overall Dimensions 267 x 326 x 273 mm / 428 x 400 x 470 mm
    Net Weight 25 kg
    Power / Voltage 1000W / AC 100–240V (50–60Hz)
