Key Features & Benefits

• High Processing Power: Delivers 20W to 1200W continuously adjustable ultrasonic output, enabling sample disruption and processing up to 1000 mL.

• Significant Noise Reduction: Complete with a dedicated soundproof box enclosure that reduces high-frequency operational noise by more than 70%.

• Heavy-Duty Horns & Transducer: Features an Alcoa 7075 transducer paired with high-purity titanium alloy horns capable of continuous ultrasonic operation for over an hour.

• Smart Touch Control & Storage: Equipped with a 4.3-inch true color capacitive touchscreen interface with MCU control, voice prompt alarms, and 20 groups of protocol memory.

• Comprehensive Automated Protections: Includes automatic no-load protection (prevents horn damage when not immersed in liquid), overload protection, temperature monitoring, and error alerts.

  ⚙️ Technical Parameters

  Parameter	Specification
  Model	BR-1200PS
  Ultrasonic Power	20 – 1200 W (Continuously Adjustable)
  Crushing / Processing Capacity	1 to 1000 mL (depending on horn selection)
  Frequency Range	19.5 – 20.5 kHz (Microcomputer Auto-Tracking)
  Display & Control Mode	True Color Capacitive Touch Screen (MCU controlled)
  Single Ultrasound / Gap Time	0.1 to 99.9 s
  Total Timer Range	1 s to 99h 59min 59s
  Duty Cycle Range	0.1% to 99.9%
  Standard / Optional Horns	Standard: Ф20 mm / Optional: Ф3, Ф6, Ф10, Ф15, Ф22, Ф25 mm
  Temperature Control Range	0 to 100°C
  Data Storage	20 Groups
  Dimensions & Host Weight	Main Unit: 410 x 225 x 290 mm / Net Weight: 15.0 kg
  Soundproof Box Enclosure	Gross Weight: 10.0 kg / Outer Packaging: 350 x 350 x 550 mm
  Power Supply	220V/110V, 50/60 Hz
