Key Features & Benefits

• Versatile 5L Heating Bath: Supports both water (up to 90°C) and oil (up to 180°C) heating with built-in dry-burning and overheat protection.

• Efficient Vapor Recovery: Double-layer vertical condenser with a large 1500 cm² cooling surface ensures rapid vapor collection and high recovery rates.

• Reliable Motor & Speed Control: Brushless DC motor offers stepless speed regulation (20 to 320 RPM) with bi-directional rotation (clockwise/counter-clockwise cycle options).

• Superior Chemical Resistance: High-elasticity graphite-filled PTFE seal with compression spring provides exceptional chemical, temperature, and abrasion resistance.

• Ergonomic & Flexible Design: Manual lift mechanism allows smooth height adjustment (180 mm) and a 0–360° tilt angle for flexible flask positioning with an integrated flask ejection mechanism.

• Enhanced User Safety: Large LED display, touch keys with mistouch prevention lock, overload protection, and auto shut-off if temperature exceeds 5°C above the set value.

  ⚙️ Technical Parameters

  Parameter	Specification
  Model	BR-RE-1000
  Max Evaporation Flask Size	3 L
  Heating Bath Capacity	5 L
  Temperature Range	Water: RT +5°C to 90°C (±1.5°C) / Oil: RT +5°C to 180°C (±3°C)
  Rotation Speed & Motor	20 – 320 RPM (1 RPM increment) / Brushless DC Motor (48W)
  Cooling Surface Area	1500 cm² (Double-layer vertical condenser)
  Lifting & Tilt Angle	Manual lift (180 mm stroke) / 0–360° tilt angle
  Timer & Cycle Interval	1–999 min (Time) / 5–999 s (Rotation interval)
  Ultimate Vacuum Degree	Max. 4 mbar (3 mmHg)
  Power Consumption	Main Unit: 48W / Heating Bath: 1300W
  Dimensions (W x D x H)	Main Unit: 400 x 320 x 540 mm / Heating Bath: 300 x 300 x 205 mm
  Weight	Main Unit: 8.6 kg / Heating Bath: 3.0 kg
