Key Features & Benefits

• Precise Feed Mechanism: Front-located feed indicator with CAM DRIVE SYSTEM for accurate feed settings from 1–50 microns in 1-micron steps.

• High-Quality Razor: Fabricated from imported fine-grain steel alloy, heat-treated for long-lasting sharpness and strength, with support for disposable blade attachments.

• Stable & Smooth Operation: Sturdy, rigid construction ensures shake-proof sectioning along with a smooth drive wheel featuring a locking mechanism.

• User-Friendly Design: Features convenient specimen holders, 360° specimen orientation adjustment with locks, protective cover for easy cleaning, and minimum maintenance requirements.

  ⚙️ Technical Parameters

  Parameter	Specification
  Available Models	BRM-1120 / BRM-1120 A
  Section Thickness Setting	1–50 microns (in steps of 1 micron)
  Knife Length	Standard 120mm (Optional: 140mm / 160mm)
  Vertical Specimen Stroke	55 mm
  Max Specimen Size	32 mm
  Specimen Orientation	360° adjustment with locks
  Knife Angle	0 to 10°
  Dimensions & Weight	300 x 300 x 240 mm / 32 to 35 kg
