Key Features & Benefits

• High Stirring Capacity: Powerful performance supports up to 20L ($H_2O$) stirring volume with speeds up to 1500 rpm.

• Ceramic-Coated Stainless Steel Plate: Provides superior heat distribution, chemical resistance, and protection against thermal shock.

• Precise PID Temperature Control: Ensures rapid heating up to 510°C with digital precision and long-term stability.

• Dual Over-Temperature Safety: Built-in hardware and software protection with a hot surface warning light above 50°C to prevent burns.

• Digital Process Timer: Supports unsupervised operations with programmable timer settings from 0 to 99h 59m.

• Durable Alloy Casing: Fully enclosed casing ensures high heat dissipation, temperature resistance, and internal component protection.

  ⚙️ Technical Parameters

  Parameter	Specification
  Model	BR-MS-2005
  Stirring Positions	1
  Plate Dimensions	185 × 185 mm
  Plate Material	Stainless steel with ceramic coating
  Max. Stirring Capacity ($H_2O$)	20 L
  Speed Range	50 – 1500 rpm
  Heating Temperature Range	Room Temp to 510°C
  Heating Output	1000 W
  External Sensor (PT1000) Accuracy	±1°C
  Safety Temperature Limit	50°C – 550°C
  Timer Range	0 – 99h 59m
  Protection Class	IP42
  Voltage / Frequency	200–240 V / 100–120 VAC, 50/60 Hz
