Key Features & Benefits

• High-Precision Thermal Control: Powered by advanced semiconductor thermoelectric cooling and PID technology for fast heating (up to 5°C/s max) and accurate temperature distribution.

• 30°C Thermal Gradient: Features a wide gradient range up to 30°C for fast and efficient PCR protocol optimization.

• Industrial 24/7 Reliability: Built with an industrial-grade operating system designed for stable, continuous round-the-clock performance.

• Compact & Ultra-Quiet: Compact footprint (200 x 300 x 170 mm) with an extremely low-noise operation profile.

• User-Friendly Touch Screen: Features a 5-inch touch screen with image-text interface for easy program editing and protocol storage.

• Advanced Safety & Automation: Smart auto shut-off heated lid (when sample is under 30°C or program ends), 16°C infinite holding mode, and protocol options for Long PCR and Touchdown PCR.

  ⚙️ Technical Parameters

  Parameter	Specification
  Model	BR-PCR-100T
  Sample Capacity	96 x 0.2 mL (non-skirted/semi-skirted PCR plates, 8×12 strip tubes, 0.2 mL single tubes)
  Block Temperature Range	4°C to 99.9°C
  Temperature Accuracy & Uniformity	±0.2°C (Accuracy) / ±0.25°C (Uniformity)
  Heating & Cooling Rates	Max Heating: 5°C/s (Avg 3°C/s) / Max Cooling: 4.5°C/s (Avg 2.5°C/s)
  Gradient Temperature Range	Max 30°C span (Accuracy: ±0.3°C)
  Heated Lid Temperature	RT+30°C to 105°C (Auto shut-off when temperature <30°C or cycle ends)
  Advanced PCR Options	Long PCR (-599s to +599s) & Touchdown PCR (-9.9°C to +9.9°C)
  Program Storage & Cycles	10,000+ programs stored, up to 99 cycles, 30 max steps
  Display & Connectivity	5-inch touch screen with image-text display; USB 2.0 port
  Dimensions & Weight	200 x 300 x 170 mm (W x D x H) / 4.5 kg
  Power Supply	AC 100–240V, 50/60Hz
