Key Features & Benefits

• Compact & Portable: Designed for mobile units, small laboratories, and on-site field testing.

• qPCR + Isothermal Dual Function: Supports both standard qPCR quantitative analysis and isothermal nucleic acid amplification.

• 4-Channel Detection: Features 4 optical channels covering major dyes (FAM, SYBR Green I, HEX, VIC, ROX, Cy5, etc.) with high-brightness LED and high-sensitivity PD detectors.

• Dual Operation System: Standalone operation using the built-in 10.1-inch color touchscreen interface or via connected PC software.

• Dual Temperature Control Modes: Flexible heating and cooling control via Block mode or analog Tube mode with high thermal accuracy (≤±0.1°C) and rapid ramp rates (≥6°C/s).

• Comprehensive Analysis Capabilities: Built-in software supports Absolute/Relative Quantification, Melting Curve Analysis, SNP Genotyping, HRM, and features power-off data protection.

  ⚙️ Technical Parameters

  Parameter	Specification
  Model	BR-QPCR-164
  Throughput & Consumables	16-well (2 x 8); 0.2ml PCR single tubes or 8-strip tubes
  Fluorescence Channels	4 Channels (Ch1: FAM/SYBR; Ch2: HEX/VIC/JOE; Ch3: ROX/Texas Red; Ch4: Cy5)
  Dynamic Range & Sample Volume	1–10¹⁰ copies / 5 to 100 μL
  Block Temperature Accuracy & Uniformity	≤±0.1°C / ≤±0.1°C
  Max Heating & Cooling Rate	≥ 6°C/s
  Heated Lid Temperature	30°C to 110°C (default 105°C)
  Display & Connectivity	10.1-inch HD touch screen; USB Type-A x2, USB Type-B, RJ45 (LIS support)
  Dimensions & Weight	288 (W) x 248 (L) x 218 (H) mm / 7.0 kg
