Key Features & Benefits
-
Gel Size up to 27 X 21 cm, accepts all kinds of present gels including proteomics large gels.
-
Transfers in as little as 15–60 minutes.
-
Minimal buffer requirements.
-
Capacity to transfer multiple gels; gels may be placed side by side or stacked, with dialysis membrane separating gel sandwiches.
-
Single-step locking system for simple, speedy setup.
-
Platinum-coated titanium anode and stainless-steel cathode plate electrodes provide consistent and reliable transfers, durability, and long lifetime.
-
Anode platform rests on 4 springs, which enables the platform to accommodate various gel stack thicknesses and produces uniform pressure on the blotting sandwich during transfer.
-
Extra plastic templates required by other semi-dry blotters are unnecessary to prevent electrode short circuits.
-
Safety cover breaks the electrical current when lifted, preventing electrical shock.
⚙️ TECHNICAL PARAMETERS:
Parameter Specification MODEL MP-3040 Maximum gel size (W x L) 27 x 21 cm Buffer requirement 200 ml Gel capacity <3, 26 x 21 gel sandwiches / 4, 13 x 10 cm gels / 6, 11 x 7 cm gels / 9, 8 x 7 cm gels Recommended power supply Power BC Dimensions (W x L x H) 39.5 x 28 x 11 cm -
Western Blotting Transfer System MP-3040
The BR Biochem Semi-Dry Western Blot System allows fast, efficient, and economical blotting without buffer tank or gel cassettes. It supports gel sizes up to 27 × 21 cm, delivers uniform and reliable protein transfer in as little as 15–60 minutes, and requires minimal buffer.
Download Technical Brochure (PDF)
