Key Features & Benefits

• 3.5 inch LCD display.

• Easy to operate and save 100 wash programs.

• Any line and hole can be easily cleaned, unnecessary to complete whole plate or strip.

• Aspirating in 2 positions, residual volume <0.7ul.

• Multi-plate can be selected by default settings or manual operation.

• Microplate holder is detachable, which makes easy to disinfect and maintain.

• Suitable for flat, U and V-bottom microplates.

• Special rinse procedure makes easy to maintain the device and reduces contamination between plates.

  ⚙️ TECHNICAL PARAMETERS:

  Parameter	Specification
  MODEL	BR-812
  Plate models	Flat-, round -, U-, V- plate (96-well and 48-well)
  Wash lines	1-12 lines selectable
  Wash times	1 to 99 times adjustable
  Residual volume	<0.7 µl/well
  Channel	8 and 12- Channel
  Wash mode	plates or strips
  Dispensing uniformity	CV < 1.5%
  Dispensing volume	50-950 µl, interval 50 µl adjustable
  Linearity	+-0.5% or <0.025A
  Repeatability Difference	<0.1% or +-0.0025A
  Row and columns difference	<0.01A
  Resolution	0.0001A
  Environment power	12V D(100V-240V wide input voltage)
  Display	External computer, shows whole results and calibration curve
