Key Features & Benefits

• Embedded 10.1 touch screen with pixel of 1920X1200, Android system with user-friendly UI design.

• Self-checking for each module during start to ensure stable and reliable measurements.

• Instrument applicable to 96-well plate, 384-well plate.

• Wavelength ranges 180-1000nm, high quality optical system based on imported monochromator with spectrometer of 1nm step accuracy.

• A measurement and reference dual-optical path system, ensures the stability of every test result.

• Qualified imported light source, lifespan flash 10⁹ time (proximate 10 years), no preheat required.

• High precise motor, fast and stable measurements.

• Various measurement modes available: Spectrum scanning, Kinetics, End point (single/double/multi wavelength).

• Incubation function with accurate temperature control.

• Oscillation function ensure sample well-mixed.

• Featured built-in data post-processing methods, including blank subtraction, standard curve fitting, result qualification, and quality control.

• Optional functions: Micro volume plate module. Cuvette module for BR-MS-200X.

• PC software, enabling network-based control and integrated management from a computer, which facilitates large-scale applications.

  ⚙️ TECHNICAL PARAMETERS:

  Parameter	Specification (BR-MS-200)	Specification (BR-MS-200X)
  Model No.	BR-MS-200	BR-MS-200X
  Cuvette detection	No	Yes
  Light Source	Xenon lamp, flash 10⁹ times	Xenon lamp, flash 10⁹ times
  Wavelength	200-1000nm	200-1000nm
  Bandwidth	< 2.5 nm (support custom made 2~10nm)	< 2.5 nm (support custom made 2~10nm)
  Wavelength accuracy	±1 nm	±1 nm
  Wavelength repeatability	±0.2 nm	±0.2 nm
  Measurement range	0-4.0 OD	0-4.0 OD
  Shaking speed	linear, 3 optional speeds	linear, 3 optional speeds
  Optical system	Grating monochromator, 1nm steps	Grating monochromator, 1nm steps
  Plate types	96-well, 384-well	96-well, 384-well
  System	Android	Android
  Weight	18KG	18KG
  Power	221W	221W
  Accuracy @450nm	±(0.5% + 0.001Abs) (0~2.0 Abs]; ±1% (2.0-3.0Abs]	±(0.5% + 0.001Abs) (0~2.0 Abs]; ±1% (2.0-3.0Abs]
  Precision @450nm	Accurate mode: CV < 0.5% or SD<0.003, Fast mode: CV < 1%	Accurate mode: CV < 0.5% or SD<0.003, Fast mode: CV < 1%
  Stability @450nm	SD<0.005Abs (0-2.0Abs]; CV< 1% (2.0-3.0Abs]	SD<0.005Abs (0-2.0Abs]; CV< 1% (2.0-3.0Abs]
  Linearity @450nm	R² >= 0.999 [0.0-3.0Abs]	R² >= 0.999 [0.0-3.0Abs]
  Incubation temperature	RT+4°C ~ 70°C (for plate)	RT+4°C ~ 70°C (for plate), RT+4°C ~ 55°C (for cuvette)
  Temperature Accuracy	±0.5°C @ 37°C	±0.5°C @ 37°C
  Temperature Uniformity	±0.5°C @ 37°C	±0.5°C @ 37°C
  Measurement speed	96-well plate (End point): Fast Mode < 6 seconds, Accurate Mode < 28 seconds	96-well plate (End point): Fast Mode < 6 seconds, Accurate Mode < 28 seconds
  Exports	2* USB A, 1* USB A(OTG), 1* Ethernet	2* USB A, 1* USB A(OTG), 1* Ethernet
  Touch screen	10.1-inch	10.1-inch
  Memory	8G storage, can save 20000+ data files	8G storage, can save 20000+ data files
  Overall Size	305 × 505 × 260 mm	305 × 505 × 260 mm
  Voltage Input	DC24V, 9.2A	DC24V, 9.2A
