Key Features & Benefits

• Microprocessor Control: Ensures steady, precise control over output parameters with continuous real-time monitoring.

• Versatile Output Modes: Supports Constant Voltage, Constant Current, and Constant Power options depending on model specifications.

• Safety & Circuit Protection: Equipped with safety mechanisms including overload protection, no-load detection, short circuit protection, and quick auto-recovery after power interruptions.

• User-Friendly Interface: Clear digital LED/LCD display allows easy navigation, setting adjustment, and status tracking.

• Compact Benchtop Footprint: Compact, light-weight design designed to occupy minimal laboratory workspace while offering multi-output jack connectivity.

  ⚙️ Technical Specifications

  1. Routine & Standard Models (BR-300N & BR-500N)

  Parameter	BR-300N	BR-500N
  Output Range	Voltage: 5 – 300V (Increment: 1V) Current: 1 – 400mA (Increment: 1mA) Power: 1 – 120W (Increment: 1W)	Voltage: 5 – 500V (Increment: 1V) Current: 1 – 400mA (Increment: 1mA) Power: 1 – 120W (Increment: 1W)
  Output Type	Constant Voltage, Constant Current, Constant Power	Constant Voltage, Constant Current, Constant Power
  Output Jacks	2 Pairs	2 Pairs
  Timer Range	1 min – 99 h 59 min	1 min – 99 h 59 min
  Display	LED Digital Display	LED Digital Display
  Dimensions (W x D x H)	280 x 237 x 118 mm	280 x 237 x 118 mm
  Weight	~ 3.0 kg	~ 3.0 kg
