Key Features & Benefits

• 100% Oil-Free Operation: Driven by a piston mechanism requiring no lubricants or oil changes, ensuring zero oil pollution and minimal maintenance.

• Inlet Filter Cartridge: Equipped with an air inlet filter cartridge that traps particles and moisture to extend pump service life.

• Adjustable Vacuum Regulation: Includes a vacuum regulator to precisely adjust vacuum levels for sensitive filtration or evaporation setups.

• Thermal Protection Safety: Built-in thermal protection device automatically shuts off the motor if overheated and resets once cooled down.

• Quiet & Compact Design: Low noise level (45 dB) and compact footprint make it suitable for comfortable benchtop laboratory use.

  ⚙️ Technical Parameters

  Parameter	Specification
  Model & Product Code	BR-100 (100BR100)
  Pump Type & Stage	Oil-Free Piston Pump / 2 Stage
  Max Vacuum	100 mbar (-710 mmHg)
  Max Flow Rate	120 L/min
  Motor Rotation	1450 RPM
  Max Power & Current	120W (1/1 HP) / 0.5 A
  Port Thread	1/4 NPT
  Noise Level	45 dB
  Overall Dimensions & Weight	250 x 180 x 150 mm / 10 kg
  Power Supply	220V, 50/60 Hz
