Key Features & Benefits

• Truly compatible with domestic and foreign brands of prefabricated glue

• Product parameters, and accessories are compatible with imported products

• The edge cushion is fixed on the long glass plate, which effectively improves the accurate alignment of the glass plate and reduces the glue leakage

• The rubber frame of the cam card lock is easy to operate, and it can accurately align the glass plate in any plane

• Special plastic Well Combs do not inhibit the gel polymerization reaction, during the built-in ridges, can effectively improve the uniform gel polymerization

• High-purity platinum electrode wire, to achieve a better conductive performance

• It can accommodate 1-4 pieces of prefabricated glue and complete up to 4 small prefabricated glue electrophoresis within 1 hour

• Lead guide device to reduce the omission of the lane or repeat the sample

  ⚙️ TECHNICAL PARAMETERS:

  Parameter	Specification
  Model	MP-8001
  Gel Number	1-4 block
  Gel Thickness	Standard Equipment: 1.0mm; Optional: 0.75mm, 1.5mm
  No. of samples	10 teeth optional 1.5 teeth;
  Glass Size	Short glass Plate (10.1×7.3cm), Long glass plate (10.1×8.2cm)
  Gel Size	Hand glue (8.3×7.3cm)
  Prefabricated glue	8.6×6.8cm
